Deze graafmachine wordt veelal ingezet voor grondwerkzaamheden rondom huizen of wegen.
Minigraver 1800 kg, 100 cm
Beschrijving
Technical specifications: 301.8C
Production year model/type 2005-2006
Engine: Mitsubishi
Cil/Turbo/intercooler 3
Engine model: L3E
Capacity in Kw/pk/Rpm: 13,5/18,4/2400
Maximum torque: Nm/rpm: x
Displacement (cm³) 952
Fuel: Diesel
Hydrauliek system:
Capacity hydraulic tank: (liter) 24
Capacity hydraulic system: (Liter) 37
Pump flow capacity: (ltr/min) 2 x 20
Auxilary flow capacity: (Liter) (option)
Maximum working pressure: (bar) 206
Dimensions & weight: Arm (std)
Operating weight cab: (Kg) 1785
Operating weight canopy: (Kg) 1680
Length transport: (mm) 3695
Height cab: (mm) 2190
Height canopy: (mm)
Height transport: (mm) 2190
Body width: (mm)
Width over tracks: (mm) 980-1340
Width dozer blade: (mm) 980-1340
Lenght tracks on the ground: (mm) 1575
Track width: (mm) 230
Ground pressure: (kg/cm²)
Gradebility: (%/°) 30°
Fuel tank: (Liter) 22
Operating information: Arm (std) long arm
Max. reach at ground level: (mm) 3610 3800
Max. loading height: (mm) 2360 2480
Max. digging depth: (mm) 2080 2320
Max. cutting height: (mm) 3350 3460
Maximum travel speed low/high: (Km/h) 2,0-4,5
Extra informatie
Dagprijs | € 178.55 |
---|---|
Weekprijs | € 445.10 |
